HR10A-10P-12S hirose 12pin and HR10A-10P-6S Hirose 6pin to DB9 Camera Signal Cable

HR10A-10P-12S hirose 12pin and HR10A-10P-6S Hirose 6pin to DB9 Camera Signal Cable

Product Details:

Place of Origin:China
Brand Name:DHT
Certification:CE/ROHS/FCC/SGS/UL
Model Number:HR050-9DB

Payment & Shipping Terms:

Minimum Order Quantity:100pcs
Price:negotiation
Packaging Details:1 piece  per PE Bag then 20pcs per carton
Delivery Time:3 - 7 working days
Payment Terms:T/T or Paypal
Supply Ability:300,000pcs per month


Detailed Product Description

Sheath Material:PVCType:Coaxial
Range Of Application:IndustrialApplication:Camera
Conductor Type:SolidMaterial Shape:Round Wire
Contact:Circular 12pinConnector::12pin To Db9pin
Cable:Chain FlexLength:0.3m~25m


HR10A-10P-12S hirose 12pin and HR10A-7P-6S Hirose 6pin to DB9 Camera Signal Cable


Description

Connector:

one end:HR10A-10P-12S(73)Female / HR10A-7P-6S Female

2nd end: D-sub 9pin female / D-sub 15pin / D-sub 25pin Female


Cable:Camera signal Cable

Length: 0.5m 1.0m 2.0m 5.0m customized length


Specification


This cable assembly can be connected to industrial camera / Security camera with hirose 12Pin connector HR10A-10R-12P and Lens with equivilent Hirose 12Pin HR10A-10R-12P(73) receptacle,other end to image processing device or equipment with DB 9Pin male conector.


The cable body can be used with standard cable and high flex cable,cable length can be customized,the Contact connector can be with male or female,the connection orientation can be made as straight type and right angle type.


12Pin to Db9pin Hirose Cable Automation Data Transmission 0.3m ~ 25m
