Hirose 12 pin Right Angle Cable with Compatiable HR10A-10LP-12S Circular Push Pull Connector

Product Details:

Place of Origin:China
Brand Name:DHT
Certification:CE/ROHS/FCC/SGS/UL
Model Number:12pin CCXC SONY CAMERA CABLE

Payment & Shipping Terms:

Minimum Order Quantity:100pcs
Price:negotiation
Packaging Details:1 piece  per PE Bag then 20pcs per carton
Delivery Time:3 - 7 working days
Payment Terms:T/T or Paypal
Supply Ability:300,000pcs per month


Detailed Product Description

Product Name:Hirose CableMaterial:Copper
Interface Type:HirosePin:12pin
Application:Industrial Machine Vision,SecurityPower Cable Type:Two-pin
Feature:High FlexShape:Round
Computer Cable Type:Power LinePrinter Cable Type:Parallel
Color:Black25meters:Overmolded
5meters:High Flex Chain Black


Hirose 12 pin Right Angle Cable with Compatiable HR10A-10LP-12S Circular Push Pull Connector


Product Description:


Equal to Hirose HR10A-10LP-12S,right angle HRS Circular Push Pull Connectors 12P Plug Shell SZ 10 Female
RoHS right-angle plug connector with silver-plated socket terminals – plug compatible with Hirose HR10A-10LP-12S RoHS version with silver plating


Cable: 24AWG*12 12 core twisted cable for power supply,trigger wire, I/O cable

2 core non twisted cable for power supply

pin assignment and color code can made according to customers' requirements

Length: 0.5meters, 1meters, 1.5meters,2meters,3meters,5meters,10meters

Color: Black / Grey

Flying leads : Standard and custom


Features:

  • Hirose(Japan original) and equivilent HR10A-10P-12S domestic high quality brand connector,6hole/8hole/12hole for options: 12 Pin Female Plug HR10A-10P-12S and 8 Pin Female Plug HR25-7TP-8S and 6 Pin Female Plug HR10A-7P-6S

  • Conforms to the UL standard,combustion level VW-1

  • RoHS

  • Aluminum foil braid shielding layer,high resistance to external interference

  • Multi stranded pure copper conductor with stable transmission and bending resistance

  • High flex attribution allow the power I/O cable moving with cameras
